Ganfeng 3.2V 100Ah Prismatic LiFePO4 Battery Cell (Grade A)

Name: Ganfeng 3.2V 100Ah Prismatic LiFePO4 Battery Cell (Grade A)
Brand: Volt Edge Power Solutions
Price: 10500.00 PKR
Availability: InStock

Rs.10,500.00

Sale Sold out

Key Highlights

Ultra-Long Cycle Life: Up to 6,000 cycles at 80% Depth of Discharge (DoD).
High Thermal & Chemical Safety: Advanced Lithium Iron Phosphate $LiFePO4$ chemistry prevents thermal runaway.
Low Internal Resistance: < $0.4m$ impedance for high power delivery and minimal voltage drop.
Wide Operating Range: Ideal for domestic energy storage, solar inverters, UPS systems, and electric mobility.

Technical Specifications

General Information

Parameter	Specification
Brand / Manufacturer	Ganfeng Lithium (GFB)
Battery Chemistry	Lithium Iron Phosphate $LiFePO4$
Form Factor	Prismatic
Nominal Voltage	$3.2V$
Nominal Capacity	$100Ah$
Stored Energy	$320\Wh$
Charging Temperature	$0C$ to $55C$
Discharging Temperature	$-20C to 55C$
Storage Temperature	$-20C$ to $45C$
Self-Discharge Rate	$3.5%$ per month
Dimensions ( $L times W times H$ )	$173.9 mm times 48.0mm times 127.6mm$ (approx.)
Weight	$2.3 Kg (approx)$
Terminal Connection	M6 Screw / Laser Welded Studs
